Brand: Generic (Imported)
50g to 5000g Semi Automatic Pulses/Seeds/Grains Filling Machine 500W
SKU: PD-DI-20223173
₹57999 (Including GST)
Get extra ₹870 Discount (On Checkout)
Delivery By: Feb 10 - Feb 12
Qty:
Easy Return
& Refund
Quality
Assurance
Trusted
Delivery
After Sales
Assistance
Buyer
Protection
Short Description
Semi Auto Weighing Filling Machine 50-5000 g
Filling Speed 10-25 times per min
15 Kg Hopper Capacity
Country of origin: China
Description
This Semi automatic powder weighing filling machine is used to accurately weigh and fill ultra-fine particles. Signals from the weight sensor are denoted on the Digital display showing the particle output's weight. This Machine Works from data to potato chip filling.
Features
:- Capacity Range : The semi-automatic filling machine is designed to handle a wide range of product weights, specifically from 50 grams to 5000 grams. This versatility allows it to accommodate various packaging needs for different types of pulses, seeds, and grains, making it suitable for small-scale operations as well as larger production runs.
- Control System : This semi-automatic machine come equipped with user-friendly control panels that allow operators to set desired weights easily and monitor the filling process in real-time.
- Adjustable Settings : The ability to adjust settings such as fill speed and weight calibration is crucial for optimizing performance based on product characteristics.
- Power Specifications : With a power rating of 500 watts, this machine provides sufficient energy to operate effectively while maintaining efficiency.
Specification
:- Product Type: Granule Filler
- Brand: Generic (Imported)
- Weight (Approx.) : 57.6 kg
- Power Source : Electric
- Power : 500W
- Weighting Range : 50-5000 g
- Filling Speed : 10-25 times per min (Depending on Materials & Diff. Aliquot Weight)
- Filling Accuracy : +- 2 Gm (Depending on Material)
- Hopper Capacity : 15Kg
- Automation Grade : Semi-Automatic
- Dimensions (L x W x H) : 700 x 420 x 1370 mm
- Weight : 57.6 Kg (Approx.)
NOTE :
- Not suitable for ingredients with moisture content
- Not suitable for powder filling
- Panel design may vary
Usage
:1. Setup the Machine :
- Place the machine on a stable, flat surface.
- Ensure that it is connected to a power source and that all components are securely attached.
2. Adjust the Filling Volume :
- Set the desired filling volume between 50 to 5000 grams using the control panel.
- Calibrate the machine if necessary, following manufacturer instructions for accuracy.
3. Prepare the Granules :
- Ensure that the granules you intend to fill are clean and free from moisture.
- Place the granules in the hopper of the machine.
4. Start the Filling Process :
- Activate the machine using the start button or switch.
- The machine will automatically dispense the set amount of granules into containers or bags placed below.
5. Monitor and Adjust :
- Keep an eye on the filling process to ensure consistency and accuracy.
- Make any necessary adjustments to settings if inconsistency occur.
Maintenance :
- Check Power Supply : Ensure there are no issues with the power supply and that the insulation layer is intact.
- Sanitation : Clean all material contact parts to maintain hygiene and prevent contamination.
Applications
:- Agricultural Industry : Granules and pellets in agriculture, such as fertilizers, pesticides, and herbicides, are often filled into bags or containers using semi-automatic granule filling machines.
- Pet Food Industry : Semi-automatic granule filling machines are used for packaging various types of pet food, such as granulated dry food or treats.
- Retail Packaging : Perfect for small businesses to package products like tea, coffee, and other granulated items.
- Food Industry : Ideal for filling granules like rice, sugar, spices, and other food products.
Shipping Weight & Dimensions
: Package Dimensions
(L X W X H)
: 10 cm X 10 cm X 10 cm
Package Weight
:
64.00 Kg
