Brand: Generic (Imported)
Heavy Duty Commercial Single Head 10-100 ml Paste Filling Machine
SKU: DM-OM-20234452
₹45799 (Including GST)
MRP : ₹50000
Get extra ₹687 Discount (On Checkout)
Delivery By: Feb 9 - Feb 11
Qty:
Easy Return
& Refund
Quality
Assurance
Trusted
Delivery
After Sales
Assistance
Buyer
Protection
Short Description
Heavy Duty Commercial Single Head 10-100 ml Paste Filling Machine
10-100 ml Filling Volume
600 Bottles/Hour Efficiency
Country of origin: China
Description
This Machine is a semi-automatic piston type Paste Filling Machine This machine is reasonable in design, small, and exquisite in model. Both filling volume and filling speed can be adjusted at will, filling accuracy is high. The filling head adopts an anti-leakage technology.
Features
:- Filling Range : This machine is capable of filling products within a range of 10 to 100 ml, allowing for versatility in packaging different product sizes.
- Advanced Technology : It utilizes advanced filling technology that ensures accurate and consistent filling. This precision minimizes product wastage and enhances overall production efficiency.
- Durable Construction : Constructed from high-quality stainless steel, the machine is built to withstand heavy usage while ensuring hygiene standards are met, especially important in food and pharmaceutical applications.
- Compact Design : Its compact design makes it suitable for both small-scale and large-scale production facilities, optimizing space without compromising on performance.
Specification
:- Product Type: Paste Filler
- Brand: Generic (Imported)
- Weight (Approx.) : 23.9 kg
- Body Material : Stainless Steel
- Power Source : 220V
- Phase : Single
- Frequency : 50Hz
- Filling Head : Single Head
- Filling Volume : 10-100 ml
- Capacity of Hopper : 20 L (Depending on material)
- Air Supply : 200 LPM
- Air Pressure : 0.6 Mpa
- Efficiency : 600 Bottles/Hour
- Weight : 23.9 Kgs (Approx.)
NOTE :
- Package will be shipped in 2 packages
- This machine is not suitable for Grease filling.
Usage
:Setup the Machine :
- Place the machine on a stable, flat surface.
- Ensure that all parts are securely assembled according to the manufacturer’s instructions.
Adjust the Filling Volume :
- Set the desired filling volume (between 10-100 ml) using the adjustment knob.
Prepare the Paste :
- Ensure that the paste is at an appropriate viscosity for filling. If necessary, mix or dilute it to achieve optimal flow.
Fill the Hopper :
- Pour the prepared paste into the hopper of the machine, ensuring not to overfill.
Select Operating Mode :
- Choose between manual or automatic mode based on your production needs.
Start Filling Process :
- Press the start button or activate the foot pedal to begin filling.
- Monitor the process to ensure consistent filling and check for any clogs or issues.
Collect Filled Containers :
- Position containers under the nozzle to catch filled paste.
- Ensure containers are stable and aligned properly for accurate filling.
Maintenance :
- Regular Cleaning : After each production run, thoroughly clean all parts that come into contact with the paste. This includes the filling nozzle, hopper, and any other components.
- Inspection for Wear and Tear : Conduct regular visual inspections to check for signs of wear, leaks, or corrosion on seals and gaskets.
Applications
:- Food Industry : It is suitable for filling sauces, jams, and other thick food products.
- Cosmetics : The machine can fill creams, lotions, and gels used in personal care products.
- Pharmaceuticals : It is utilized for dispensing ointments and other viscous medicinal products.
- Chemical Industry : The machine can handle adhesives and other thick chemical substances.
Shipping Weight & Dimensions
:This product will be shipped in 2 packages.View All
