Automatic Batch-Coding Printer with 50mm Printing Head for Conveyor, without Cartridge
SKU: SI-PT-14745
₹42190 (Including GST)
Get extra ₹633 Discount (On Checkout)
Delivery By: Apr 8 - Apr 10
Qty:
Easy Return
& Refund
Quality
Assurance
Trusted
Delivery
After Sales
Assistance
Buyer
Protection
Short Description
Automatic Batch-Coding Printer with 50mm Printing Head for Conveyor
600 dpi Maximum Resolution
25.4 mm Printing Height
25.4 mm Printing Height
Country of origin: China
Description
This Automatic Batch-Coding Printer with a 50mm Printing Head for Conveyor is an industrial inkjet printing system designed to print variable information such as text, barcodes, and expiration dates directly onto products or packaging as they move along a conveyor belt. This type of printer features a fixed print head that allows for high-speed, continuous printing while maintaining alignment with the production line’s pace.
Features
:- Easy to operate with user friendly panel.
- Handy, portable and easy to carry.
- Anti scratch and free flowing print nano technology added in this machine.
- Suitable for printing Bar code, QR, Batch code, MRP, Dates, Images etc
Specification
:- Brand: Generic (Imported)
- Weight (Approx.) : 2 kg
- Power Source : Electric
- Adaptor : 16V/2A
- Maximum Resolution : 600 dpi
- Printing Height : 25.4 mm/ 1 inch
- Screen Size : 10 Inch
- No of heads : 2
- Humidity : 10% - 80%
- Connector Type : USB
- Print Content : Text, Image, Barcode, QR etc
- Printing Material : Paper, Stone, Pipe, Cable, Metal, Plastic, Wood etc
- Temperature : 0-45oC
- Printing Distance Adjustment : Available
- Printing Length : As per your requirement.
- Printing type : Dot Metrics and Normal both.
Note :
- Calibration required for the first time using the machine.
- Cartridge is not include with the product.
Precautions Guidelines :
Buy best quality verified Ink Cartridges from Toolsvilla with best quality Ink offered at best price. Be aware of fraudulent duplicate Ink Cartridges available in the regular market as it might affect your machine's performance and printed Inks longevity will decrease.
Usage
:1. Setup the Printer :
- Place the automatic batch-coding printer on a stable surface near the conveyor system.
- Ensure that the printer is connected to a power source and that all necessary cables are securely attached.
2. Connect to Conveyor :
- Align the printer’s printing head with the conveyor belt where products will pass through.
- Adjust the height and angle of the printing head to ensure proper contact with the products.
3. Load Ink :
- Open the ink compartment of the printer and insert the appropriate ink cartridge (not included).
4. Configure Settings :
Use the printer’s control panel or software interface to set up printing parameters such as:
- Print resolution (max 600 DPI)
- Content type (text, date, barcodes, QR codes)
- Variable serial numbers if needed.
5. Test Print :
- Run a test print by activating the conveyor system and observing if the print quality meets your standards.
- Make any necessary adjustments to alignment or settings based on test results.
6. Start Production :
- Once satisfied with test prints, begin production by allowing products to pass through the conveyor system.
- Monitor print quality regularly and check for any ink issues or misalignments during operation.
Maintenance :
- Installation and Environment : Ensure the printer operates in a controlled environment, ideally at room temperature. Avoid high humidity, acidic, or alkaline conditions to maintain efficiency and precision.
- Daily Cleaning Procedures : After each shift, clean the work surface to prevent residue build-up.
Applications
:- Packaging Industry : The printer is used for printing batch numbers, expiry dates, manufacturing dates, product codes, and other essential product information on the packaging (like boxes, bottles, or cartons).
- Food and Beverage Industry : Automatic batch-coding printers help print batch numbers, expiration dates, and best-before dates on food packaging materials.
- Pharmaceutical Industry : Pharmaceutical products must have clear labeling for compliance with regulations. The printer marks batch numbers, production dates, and expiration dates on drug packaging or bottles.
- Cosmetics Industry : Batch-coding printers mark the product's production batch, expiry date, or other regulatory information required on cosmetic product containers, boxes, or labels.
