Brand: TOTAL
Total Silver & Blue Autorange Multimeter TMT47504
SKU: TI-TA-21742
MRP : ₹4799
Offer Price : ₹3199 (Including GST)
Get extra ₹48 Discount (On Checkout)
Delivery By: Dec 31 - Jan 2
Qty:
BUY IN BULK
Easy Return
& Refund
Quality
Assurance
Trusted
Delivery
After Sales
Assistance
Buyer
Protection
Short Description
Total Autorange Multimeter TMT47504 is designed to measure a wide range of electrical parameters, the Total Auto range Multimeter TMT47504 is a digital multimeter is both versatile and easy to use. Accurate readings for AC and DC voltages (up to 1000V), currents (up to 10A), resistance (up to 60MΩ), capacitance, frequency, and duty cycle are made possible by its true RMS display with 6000 counts. The device has numerous test modes, including continuity and diode testing, data hold functionality, and non-contact voltage sensing. It also has an input LED indicator, excessive voltage prompt notifications, a low battery indication feature, and a backlight for visibility in low light. The multimeter is ideal for both professional and do-it-yourself applications because it is small and light (0.63 kg).
Country of origin: China
Description
Total TMT47504 is intended to measure several electrical properties such as voltage, current, resistance, capacitance, frequency, and duty cycle. With a count of 6000 on its genuine RMS (Root Mean Square) display, it provides precise readings over a wide range of measurements. Both alternating current (AC) and direct current (DC) measurements are supported by the multimeter.
Features
:- It has a True RMS display with 6000 counts, allowing for accurate readings of both AC and DC voltages.
- Diode test and continuity test functions.
- Temperature measurement capability.
- Data hold function allows users to freeze the reading on the display.
- Sound and light indicators for Non-Contact Voltage (NCV) detection.
- Input LED indication and high voltage prompt features enhance user safety.
- Backlight function for visibility in low-light conditions.
- Flashlight function included for convenience during use in dark areas.
- Low battery indicator alerts users when battery replacement is needed.
Specification
:- Product Type: Hand Tools Kits
- Brand: TOTAL
- Model No : TMT47504
- Brand : Total
- Product Type : Autorange Multimeter
- Color: Silver & Blue
- Dimension：24 × 10 × 6 cm (LxWxH)
- Frequency :10Hz/100Hz/1000Hz/10KHz/100KHz/1000KHz/10MHz±(1.0%+3)
- Resistance : 600Ω/6kΩ/60kΩ/600kΩ ±(1.0% +3)，6MΩ/60MΩ±(1.5%+3)
- DC Current: 600μA/6mA/60mA/600mA/10A ±(1.2% +3)
- Voltage (AC):600mV/6V/60V/600V/750V±(0.8%+5)
- Capacitance: 10nf/100nf/1000nf/10μF/100μF/1000μF ±(4.0%+5) ，10mf/100mf±(5.0%+5)
- AC Current (A):600μA/6mA/60mA/600mA/10A ±(1.5% +3)
- Voltage (Dc): 600mV/6V/60V/600V/1000V ±(0.5% +3)
- Suitable for : Voltage Measurement, Current Measurement, Resistance Measurement, Capacitance Measurement, Frequency Measurement, Temperature Measurement, Diode Testing, Continuity Testing etc.
- Weight: 630 Gm.(Approx.)
Shipping Weight & Dimensions
:
Verified Package Dimensions
(L X W X H)
: 20 cm X 14 cm X 8 cm
Package Weight
:
0.65 Kg
